Spherical Pressure Regulating Valve With Glass Cover
WH-5107A
The valve is applied to pressure vessel pipeline system
- Product Introduction
The Spherical Pressure Regulating Valve with Glass Cover is a highly reliable and efficient pressure regulating valve designed for use in industrial applications. This valve features a durable and compact design with a glass cover that provides easy visibility of the valve's operation. It is highly adjustable and can be tailored to meet specific pressure control needs, making it ideal for a wide range of industrial processes.
The valve is manufactured using high-quality materials that ensure maximum durability and long-term performance. It is also highly resistant to corrosion and abrasion, making it suitable for use in harsh environments.
The with Glass Cover is easy to install and maintain, with minimal maintenance needed to keep it running smoothly. It is also designed to offer precise control, ensuring that pressure is maintained within optimal levels to promote efficient and safe operation. Overall, it is an excellent choice for industrial applications that require precise pressure control and durable equipment.
Introduction to Functions and Characteristics
The valve is applied to pressure vessel pipeline system.
Regulating the one-way exhaust valve protects the vessel from explosion when the pressure is higher than the set pressure (standard 1BAR). On the contrary, it can exhaust when the pressure is higher than the set pressure (standard 1BAR). The pressure on the regulating rod is calibrated. The required pressure is adjusted according to the calibration. The exhaust gas at the outlet can be recovered and discharged outdoors. Adding water to the glass cover can see the fermentation effect and reduce dyeing. Bacteria. The valve is easy to use, accurate calibration, but also can meet the needs of a variety of production processes, applicable to a variety of food processing, beer, beverage and pharmaceutical industries.
Technical data:Working Pressure，Pressure adjusting range 0.2-2.2bar 1.1-3.2bar
| No | Name | Material |
| 1 | Chuck | SS304 |
| 2 | O-ring | EPDM |
| 3 | Gasket | EPDM |
| 4 | Valve seat | SS304 |
| 5 | Valve body | SS304 |
| 6 | O-ring | EPDM |
| 7 | Valve element | SS304 |
| 8 | Ejector pin | SS304 |
| 9 | Spring seat | SS304 |
| 10 | Seat | SS304 |
| 11 | Spacer bush | SS304 |
| 12 | Adjusting rod(scale) | SS304 |
| 13 | Pull the ball | SS304 |
| 14 | Clamp | SS304 |
| 15 | Gasket | EPDM |
| 16 | Elbow | SS304 |
| 17 | Body seat | SS304 |
| 18 | Body core | SS304 |
| 19 | O-ring | EPDM |
| 20 | Ventilator sleeve | SS304 |
| 21 | Glass cover | Organic glass |
| 22 | Exhaust hood | PTFE |
| 23 | Gland | SS304 |
| 24 | 90 degree hose joint | SS304 |
| Size | D1 | D2 | D3 | D4 | D5 | D | H1 | H | H2 |
| 1.5" | Φ50.5 | Φ35 | Φ40 | Φ60 | Φ15 | 160 | 256 | 272 | 102 |
