Adjustable Vacuum Pressure Relief PVRV Valves
WH-5102(3.5 inch PVRV)
The breathing valve has two functions. When the pressure is higher than the set pressure (standard 1BAR), it can be vented, and vice versa.
- Product Introduction
Application
Breather valves are safety devices required for storage tanks/containers/gas or vapor pipe lines/ reactors etc. having chemicals or any other fluid to be handled carefully.Breather valves with desiccants are used during transportation of sensitive equipments/ goods to protect from pressure differentials due to change in climatic conditions.
We manufactures Pressure Vacuum Relief Valves (PVRV), Breather Valves, Safety Relief Valves and Vacuum Breaker Valves of wide range to meet the industry requirements.
In case of combustible fluids storage the safety valves should be used along with flame arrestors.
Size | D2 | D1 | D3 | H |
Φ34 | Φ34 | Φ25 | Φ30.5 | 49mm |
1” | Φ34 | Φ25 | Φ30.5 | 49mm |
1.5” | Φ50.5 | Φ35 | Φ42 | 72mm |
2” | Φ64 | Φ47 | Φ51 | 85mm |
2.5” | Φ78 | Φ59 | Φ64 | 90mm |
3.5” | Φ105 | Φ83 | Φ88 | 135mm |
Technical parameters: Interface: clamp Pressure: 0.2mpa Temperature: -30C. +150c. Working medium: gas
Installation informations
Fitting position
The bunging fitting is to be installed at the connection (1)
Pressure setting
The set pressure can be adjusted by the spring (8) force according to the operation pressure of the tank
NOTE
The valve need to be cleaned when the seal covered with impurities and cannot close tight enough, which could following with leakage. (see 7 Manual Operation )
Vacuum Safety Valve Product Overview:
Wenhan vacuum safety valve is suitable for vacuum system with temperature ≤150°C. When the negative pressure in the container exceeds the allowable value, the valve will automatically open and take in air; when the negative pressure in the container reaches the allowable value, the valve will automatically close. Protection of equipment and systems.
FAQ:
Sample which we have in stock, will be sent to you within 1 working day.
OEM sample, will be sent to you within 3 working days.
Quality control
We have a strict quality control system, Professional QC team.
Quick response
All requests will be reply within 1 hours.
How long i can get the feedback after we sent the enquiry?
We will reply you within 1 hours in working day.
NO | Name | Material |
1 | Valve body | SS304 |
2 | Valve element | SS304 |
3 | Filler plate | EPDM |
4 | The valve core seat | SS304 |
5 | Negative pressure small spring | SS304 |
6 | Snap spring | SS304 |
7 | Positive pressure spring | SS304 |
8 | locknut | SS304 |
9 | Blind nut | SS304 |
Application Scene
