Sanitary Quick Fitting Tee
.
- Product Introduction
Sanitary Quick Fitting Tee is a high-performance product designed for use in the food and beverage industry as well as the pharmaceutical industry. Its unique design and construction provide excellent resistance to corrosion and chemical contaminants, making it an ideal solution for applications requiring high levels of cleanliness and hygiene.
The key feature of this product is its quick-connect design, which makes it easy to install and maintain, while also reducing the risk of contamination. With no tools required for installation, this tee fitting is a cost-effective and efficient solution for connecting pipes and hoses, speeding up production processes and reducing downtime.
Quick Details:
Place of Origin:Ningbo,China
Brand Name:Wenhan
Connection:Flange
Shape:Equal, Equal
Model Number:Tee
Head code:Square
Material:Stainless Steel 304
Size:16mm-1020mm
Application:Liquid,Oil,Gas.Vapour
Technics:Casting
Product name:304/316l Stainless Steel Sanitary fitting quick chunk tee
Max Operating Pressure:150LBS
Threaded Standard:Polishing
304/316L Stainless Steel Sanitary Fitting Quick Chuck Tee Food Grade Polishing Pipe Fitting
Process | Inside and outside polishing |
Connection method | Chuck type |
Material | Stainless Steel SUS304(Customizable SUS316/SUS316L) |
Max Operating Pressure | 150LBS |
Size | 16mm-1020mm |
Application Medium | Liquid,Oil,Gas,Vapour |
Scope of Application | Household fitting,auto parts,medical equipment,building materials,chemicals,food industry,agriculture,ship parts,etc. |
Unit Conversion
Inch | DN | 钢管外径Steel Pipe Outer Diameter I Series II Series | PE管外径 Outer Diameter | 螺纹直径 Thread Diameter | |
3/8" | DN10 | 17.2 | 16 | - | 16 |
1/2" | DN15 | 21.3 | 19 | Φ20 | 20 |
3/4" | DN20 | 26.9 | 25 | Φ25 | 26 |
1" | DN25 | 33.7 | 32 | Φ32 | 32 |
11/4" | DN32 | 42.4 | 38 | Φ40 | 41 |
11/2" | DN40 | 48.4 | 45 | Φ50 | 47 |
2" | DN50 | 60.3 | 57 | Φ63 | 59 |
21/2" | DN65 | 76.1 | 76 | Φ75 | 75 |
3" | DN80 | 88.9 | 89 | Φ90 | 89 |
4" | DN100 | 114.3 | 108 | Φ110 | 113 |
5" | DN125 | 140 | 133 | Φ125 | - |
Φ140 | - | ||||
6" | DN150 | 168.3 | 159 | Φ160 | - |
8" | DN200 | 219.1 | 219 | Φ200 | - |
Φ250 | - | ||||
10" | DN250 | 273 | 273 | Φ250 | - |
12" | DN300 | 323.9 | 325 | Φ315 | - |
14" | DN350 | 355.6 | 377 | Φ355 | - |
16" | DN400 | 406.4 | 426 | Φ400 | - |
18" | DN450 | 457 | 480 | Φ450 | - |
20" | DN500 | 508 | 530 | Φ500 | - |
24" | DN600 | 610 | 630 | Φ630 | - |
28" | DN700 | 711 | 720 | Φ710 | - |
32" | DN800 | 813 | 820 | Φ800 | - |
36" | DN900 | 914 | 920 | Φ900 | - |
40" | DN1000 | 1016 | 1020 | Φ1000 | - |
